Product feature

1.Rail is made of special stainless steel, with high rigidity, corrosion resistance,

2.Connecting pin is made of high strength alloy steel with impact resistance and long service life.

3.Adjustable stroke equipment is available, and can directly replace the oil shock absorber.

4.The guide rail has excellent straightness and no turning accuracy.

5.Sensors can be installed easily at cylinder surrounding grooves.

6.Body and slider with positioning pin hole which can improve the precision and the consistency of repeated dismounting and positioning.

Installation and application

1. Dirty substances in the pipe must be eliminated before cylinder is connected with pipelline to prevent the entrance of impurities into the cylinder.

2. The medium used by cyllinder should be filtered to 40μm or below.

3. Anti-freezing measure shall be adopted under low temperature environment to prevent moisture freezing.

4. If the cylinder is dismantled and stored for a long time, pay attention to conduct anti-rust treatment to the surface. Anti-dust caps shall be added in air inlet and outlet ports.
