1.Manufactured by our enterprise.

2.There are several ways to fix the cylinder and it is convenient to install and use.

3.Several cylinders can be assembled together to effectively save the installation space.

4.The guide precision ofpiston rod is high and no additional lubricant is needed.

5.Cylinders ofvarious specifications are optional.

6.The seal material with high temperature resistance is adopted to guarantee the normal operation of cylinder at150℃(Option).

Installation and application

1. When load changes in the work, the cylinder with abundant output capacity shall be selected.

2.Relative cylinder with high temperature resistance or corrosion resistance shall be chosen under the condition of high temperature or corrosion;

3. Necessary protection measure shall be taken in the environment with higher humidity, much dust or water drops, oil dust and welding dregs,

4. Dirty substances in the pipe must be cleared away before cylinder is connected with pipeline to prevent the entrance of particles into the cylinder.

5.The medium used by cyllinder shall be filtered to 40μm or below.

6. As both of the front cover and piston of the cylinder are short, typically too large stroke can not be selected.

7.Anti-freezing measure shall be adopted under low temperature environment to prevent moisture freezing.

8.The cylinder shall avoid the influence of side load in operation maintain the normal work of cylinder and extend the service life.

9. If the cylinder is dismantled and stored for a long time, pay attention to conduct anti-rust treatment to the surface. Anti-dust caps shall be added in air inlet and outlet ports.
